Shearing Force Tester RD-SF2008B

Shearing Force Tester RD-SF2008B

Presentation:Available for shearing force testing before mass production

Advantage:Durable, Max. market share in China local brands

Application:RFID inlay, label manufacturer

Brochure Download:Down

Equipment Description
This device is widely used for the shearing force testing before mass production. Easy operation and it’s the essential assistant device for RFID labels manufacturers or R&D enterprise.

Technical Characteristic
1. By use of Zoom-stereo microscope from 7 to 45 in amplification range
2. Special push-type broach design is more available in RFID using.
3. High standard push-pull tester to ensure the range to 5kgf.
4. Automatic clamping for labels and support vacuum sorb function
5. Position of push-type broach is available for micro-adjustment of L/R, H/L
6. Controlled by PLC+ Touch Screen, the broach supports adjustment for rate/route of travel.
7. Good appearance and durable for using in long time
